| Capacity | 256GB/512GB/1TB/2TB |
| Form factor | M.2 2280 |
| NAND Flash | 3D NAND |
| Dimensions (L x W x H) | 80 x 22 x 3.13mm / 3.15 x 0.87 x 0.13inch (with heat sink) |
| 80 x 22 x 2.15mm / 3.15 x 0.87 x 0.09inch (without heat sink) | |
| Weight | 9g / 0.32oz (with heat sink) |
| 6.2g / 0.22oz (without heat sink) | |
| Interface | PCIe Gen3 x4 |
| Sequential Read (Max) | Up to 2,000MB/s* |
| Sequential Write (Max) | Up to 1,600MB/s* |
| Operating temperature | 0°C - 70°C |
| Storage temperature | -40°C - 85°C |
| Shock resistance | 1500G/0.5ms |
| MTBF | 1,500,000 hours |
| Terabytes Written (TBW) | 480TB** |
